Main Features：
1. Pure Sine Wave
2. Output power factor 1
3. Colorful LCD display
4. Working mode and parameters can be settable via LCD display, such as : charging current , input voltage range , AC/Battery input priority , battery type, charging voltage and etc...
5. Low frequency design for inductive loads
6. Auto rstart while AC is recovering
7. smart battery charger system for optimized battery performance
8. Support use Lithium batteries
9. Protect: Over-load protect, short circuit protect, over-current protect, over voltage protect, over temperature protect
| Model |
RP 3000 |
RP4000 |
RP5000 |
RP6000 |
| Rated Power |
3000W |
4000W |
5000W |
6000W |
| INPUT |
| Voltage |
100/110/120Vac;220/230*/240Vac |
| Selectable Voltage Range |
Wide Range : 75vac~138Vac; 155Vac~275Vac(for home appliances)
Narrow Range: 82Vac~138Vac; 165Vac~275Vac(for personal computer) |
| Frequency Range |
40-70Hz( 50Hz/60Hz) |
| OUTPUT |
AC Voltage Regulation
(Batt. Mode) |
100/110/120Vac;220/230*/240Vac |
| Surge Power |
9000VA |
12000VA |
15000VA |
18000VA |
| Efficiency (Peak) |
91% |
| Transfer time |
<10ms |
| Waveform |
Pure sine wave |
| BATTERY |
| Battery Voltage |
24V |
48V |
24V |
48V |
24V |
48V |
24V |
48V |
| Charge current |
50A |
25A |
70A |
35A |
75A |
45A |
75A |
50A |
| Fast charge voltage |
28.6VDC |
57.2VDC |
28.7VDC |
57.3VDC |
28.8VDC |
57.4VDC |
28.9VDC |
57.5VDC |
| Float charge voltage |
27.4VDC |
54.8VDC |
27.5VDC |
54.9VDC |
27.6VDC |
54.10VDC |
27.7VDC |
54.11VDC |
| Over voltage portect |
33.0VDC |
66.0VDC |
33.1VDC |
66.1VDC |
33.2VDC |
66.2VDC |
33.3VDC |
66.3VDC |
| Battery low voltage alarm |
21.0VDC |
42.0VDC |
21.1VDC |
42.1VDC |
21.2VDC |
42.2VDC |
21.3VDC |
42.3VDC |
| Battery low voltage shutdown |
20.0VDC |
40.0VDC |
20.1VDC |
40.1VDC |
20.2VDC |
40.2VDC |
20.3VDC |
40.3VDC |
| Protection |
Over charging,over temp, over battery voltage, over load,short-circuit |
| Operating environment Temp |
55°C |
| Cooling |
Intelligent Fan |
| Display |
Color LCD |
| Paramerter setting |
By LCD or Position Machine:
Charging current , battery type , input voltage , output frequency, Wide and Narrow range of ac input voltage , Power saver mode, ac/battery priority |
| PHYSICAL |
| Dimension D*W*H(mm) |
500*258*190 |
574*345*197 |
| Net Weight(kgs) |
25.2/24.6 |
34.4/33.8 |
37.9/38.2 |
41.6/40.5 |
| ENVIRONMENT |
| Humidity |
5-95% Relative Humidity (Non-condensing) |
| Operating Temp |
.-10°C to 50°C |
| Storage Tem. |
.-15°C to 60°C |
